LiFePO4 Lithium Battery Pack for E-Motorcycles 76.8V 20Ah – 50Ah High Power & Smart BMS
LiFePO4 Lithium Battery Pack for E-Motorcycles 76.8V 20Ah – 50Ah High Power & Smart BMS
- Overview
- Quick Details
- Specifications
- Description
- Applications:
- Competitive Advantage:
- Recommended Products
Overview
Quick Details
| Place of Origin | China |
|---|---|
| Brand Name | PittarPower |
| Model Number | LI-MOTOR-7220 / LI-MOTOR-7230 / LI-MOTOR-7250 |
| Certification | CE, RoHS (Assumed based on standard export requirements) |
Specifications
| Parameter | LI-MOTOR-7220 | LI-MOTOR-7230 | LI-MOTOR-7250 |
|---|---|---|---|
| Rated Voltage | 76.8V | 76.8V | 76.8V |
| Rated Capacity | 20Ah | 30Ah | 50Ah |
| Rated Power | 1536Wh | 2304Wh | 3840Wh |
| Compatible Motor | ≤1500W | ≤2000W | ≤2500W |
| Protection Grade | IP65 | IP65 | IP65 |
| Max Continuous Charge | 10A | 15A | 20A |
| Max Continuous Discharge | 40A | 50A | 80A |
| Dimension (mm) | 328x180x155 | 340x180x173 | 460x235x169 |
| Weight (kg) | 11 | 17 | 27.55 |
| Battery Type | LiFePO₄ | LiFePO₄ | LiFePO₄ |
| Communication | Bluetooth (std) / 1-Wire / RS485 / CAN (opt.) |
Description
Power Your E-Motorcycle with Li-Motor’s Premium 76.8V Lithium Battery Series
Li-Motor is a dedicated brand providing safe, reliable, and practical electric lithium battery solutions for 2/3/4-wheel electric vehicles. Our Electric Motorcycle Series (models LI-MOTOR-7220, 7230, and 7250) is specifically engineered for high-power electric motorcycles, delivering outstanding performance, long range, and superior safety.
Key Features & Competitive Advantages:
- Ultra-Safe LiFePO₄ Chemistry: Unlike standard lithium-ion batteries, LiFePO₄ offers superior thermal and chemical stability, eliminating the risk of explosion or combustion for maximum rider safety.
- High Voltage & Power Output: Operating at 76.8V, this series delivers strong and stable power, supporting motors from 1500W up to 2500W, ensuring excellent acceleration and climbing capability.
- Long Service Life: Designed for up to 10+ years of service life with high charge-discharge cycles, significantly reducing the total cost of ownership.
- Smart BMS Protection: Each pack features an intelligent Jiabaida BMS that monitors voltage, current, and temperature in real-time, preventing overcharge, over-discharge, overcurrent, and short circuits.
- IP65 Protection Grade: Fully protected against dust ingress and low-pressure water jets, making it suitable for outdoor riding in various weather conditions.
- Smart App Control: Standard Bluetooth connectivity allows you to monitor battery status (voltage, capacity, temperature, and health) directly from your smartphone.
- Flexible Communication: Supports 1-Wire / RS485 / CAN bus (optional) for seamless integration with the motorcycle's main controller and advanced fleet management systems.
- Fast Charging Support: Capable of 3-hour fast charging, minimizing downtime and getting you back on the road quickly.
Applications:
- High-performance Electric Motorcycles
- Electric Mopeds and Scooters
- Long-distance Commuting
- Recreational Off-road E-bikes
- Light Electric Vehicles (LEVs)
Competitive Advantage:
- 10+ Year Lifespan: Superior cycle life reduces long-term replacement costs.
- Smart Monitoring: Bluetooth app control for real-time battery management.
- Robust Build: IP65 rating ensures reliable performance in diverse environments.
- Flexible Integration: Multiple communication protocols available for OEM and aftermarket systems.
