32B19LMF 12V 32Ah Sealed Maintenance Free Car Battery – JIS B19 Group, Compact Size, Reliable Starting
Compact Starting Battery for Small Passenger Cars – Maintenance-Free, Easy Installation, Strong Performance
- Overview
- Specifications
- Competitive Advantage
- About us
- Recommended Products
Overview
Description
The PITTAR 32B19LMF is a compact yet powerful 12V sealed maintenance free automotive battery designed for reliable starting, lighting, and ignition (SLI) systems. It features expanded lead-calcium alloy grids and advanced glass fiber separators, ensuring excellent high-current discharge characteristics, low self-discharge, strong cranking performance, and long shelf life. The completely sealed design eliminates the need for water addition, making it safe, clean, and maintenance-free. With a heat-sealed polypropylene container and anti-vibration construction, this battery prevents leakage and withstands various road conditions. The magic-eye indicator allows easy checking of charging status. Ideal for JIS B19 group applications with a constant charging voltage system of 13.5V–13.8V.
Quick Detail
| Brand Name: | PITTAR |
| Model Number: | 32B19LMF |
| JIS Group No.: | B19 |
| Old JIS No.: | NS40L |
| Type: | Sealed Maintenance Free (SMF) Automotive Battery |
| Voltage: | 12V |
| Capacity (20HR): | 32Ah |
| Reserve Capacity (RC): | 48 mins |
| Standard: | JIS (Japanese Industrial Standard) |
| Terminal Layout: | 0 (Left Positive) |
| Terminal Type: | A |
| Dimensions (L×W×H×TH): | 195 × 127 × 200 × 220 mm |
| Weight (±3%): | 9.7 kg |
| Certification: | ISO9001, ISO14001, UL, CE, GB/T 5008-2023 |
| Application: | Small passenger cars, light vehicles, kei cars, and compact sedans |
Specifications
| Parameter | Value |
| Model | 32B19LMF |
| JIS Group No. | B19 |
| Old JIS No. | NS40L |
| Standard | JIS (Japanese Industrial Standard) |
| Voltage | 12V |
| Capacity (20HR) | 32Ah |
| Reserve Capacity | 48 mins |
| Length | 195 mm |
| Width | 127 mm |
| Height | 200 mm |
| Total Height | 220 mm |
| Weight (±3%) | 9.7 kg |
| Layout | 0 (Left Positive) |
| Terminal | A |
| Cover Material | PP |
| Pallet Qty | 224 pcs |
| Operating Temperature | -40°C to +60°C |
| Optimum Temperature | +10°C to +30°C |
Competitive Advantage
· 25 Years of Experience: 4 production bases, 13 million KVAH annual capacity.
· Global Standards: Meets JIS, EN, BCI, AS, and SA standards.
· Advanced Manufacturing: Imported automatic lines from Canada, Italy, Korea, and Germany.
· Certified Quality: ISO9001, ISO14001, UL, CE, ROHS approved.
· Overseas Sales: Over 60% of products exported worldwide.
