LiFePO4 Lithium Battery Pack for Electric Motorcycles 76.8V 72Ah – 183Ah High Power & Heavy Duty
LiFePO4 Lithium Battery Pack for Electric Motorcycles 76.8V 72Ah – 183Ah High Power & Heavy Duty
- Overview
- Quick Details
- Specifications
- Description
- Applications:
- Competitive Advantage:
- Recommended Products
Overview
Quick Details
| Place of Origin | China |
|---|---|
| Brand Name | PittarPower |
| Model Number | LI-MOTOR-7272 / LI-MOTOR-72120 / LI-MOTOR-72183 |
| Certification | CE, RoHS (Assumed based on standard export requirements) |
Specifications
| Parameter | LI-MOTOR-7272 | LI-MOTOR-72120 | LI-MOTOR-72183 |
|---|---|---|---|
| Rated Voltage | 76.8V | 76.8V | 76.8V |
| Rated Capacity | 72Ah | 120Ah | 183Ah |
| Rated Power | 5530Wh | 9216Wh | 14054.4Wh |
| Compatible Motor | ≤2500W | ≤5000W | ≤7000W |
| Protection Grade | IP65 | IP65 | IP65 |
| Max Continuous Charge | 20A | 45A | 60A |
| Max Continuous Discharge | 80A | 150A | 200A |
| Dimension (mm) | 530x330x200 | 480x430x215 | 590x340x240 |
| Weight (kg) | 45.3 | 68.35 | 85 |
| Battery Type | LiFePO₄ | LiFePO₄ | LiFePO₄ |
| Communication | Bluetooth (std) / 1-Wire / RS485 / CAN (opt.) |
Description
Power Your High-Performance E-Motorcycle with Li-Motor’s 76.8V High-Capacity Lithium Battery Series
Li-Motor is a leading brand dedicated to providing safe, reliable, and practical electric lithium battery solutions for 2/3/4-wheel electric vehicles. Our Electric Motorcycle Series (models LI-MOTOR-7272, 72120, and 72183) is specifically engineered for high-power electric motorcycles and heavy-duty applications, delivering exceptional range, massive power output, and uncompromising safety.
Key Features & Competitive Advantages:
- Ultra-Safe LiFePO₄ Chemistry: Unlike standard lithium-ion batteries, LiFePO₄ offers superior thermal and chemical stability, eliminating the risk of explosion or combustion for maximum rider safety, even under extreme conditions.
- High Voltage & Massive Power Output: Operating at 76.8V with capacities up to 183Ah (14,054Wh), this series supports motors from 2500W up to 7000W, delivering unparalleled acceleration, climbing ability, and long-distance range.
- High Continuous Discharge Current: With a maximum continuous discharge of up to 200A, these batteries provide consistent, stable power for demanding commercial and performance applications.
- Smart BMS Protection: Each pack features an intelligent Jiabaida BMS that monitors voltage, current, and temperature in real-time, preventing overcharge, over-discharge, overcurrent, and short circuits.
- IP65 Protection Grade: Fully protected against dust ingress and low-pressure water jets, making it suitable for outdoor riding in various weather conditions, from dusty trails to rainy city streets.
- Smart App Control: Standard Bluetooth connectivity allows you to monitor battery status (voltage, capacity, temperature, and health) directly from your smartphone.
- Flexible Communication: Supports 1-Wire / RS485 / CAN bus (optional) for seamless integration with the motorcycle's main controller and advanced fleet management systems.
- Long Service Life: Designed for up to 10+ years of service life with high charge-discharge cycles, significantly reducing total cost of ownership.
Applications:
- High-Performance Electric Motorcycles
- Heavy-Duty E-scooters and E-mopeds
- Long-Distance Touring and Commuting
- Commercial Delivery Fleets (High-Capacity)
- Off-Road and Adventure E-bikes
- Industrial and Utility Vehicles
Competitive Advantage:
- Ultra-High Capacity: Up to 14kWh of energy for extended range and all-day operation.
- 10+ Year Lifespan: Superior cycle life reduces long-term replacement costs.
- Smart Monitoring: Bluetooth app control for real-time battery management and diagnostics.
- Robust Build: IP65 rating ensures reliable performance in diverse environments.
- Flexible Integration: Multiple communication protocols available for OEM and aftermarket systems.
