PITTAR DG Series Deep Cycle Pure GEL Battery 15/20 Years Floating Design Life for Solar, Wind, Marine & Deep Discharge UPS Applications
- Overview
- Quick Detail
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
PITTAR DG (Deep Cycle GEL) series is a premium range of pure gel batteries designed for both standby and frequent cyclic discharge applications under extreme environments. By utilizing strong grids, high purity lead, and patented gel electrolyte, the DG series offers excellent recovery capability after deep discharge and delivers twice the cyclic life of standard battery series.
With a floating design life of up to 15 or 20 years (depending on the specific model), these batteries are ideal for long-term, high-demand applications. They feature a wide operating temperature range (discharge: -40°C ~ 60°C, charge: -20°C ~ 50°C) and low self-discharge rate (less than 2% per month at 20°C), ensuring reliable performance even under harsh conditions.
Manufactured with ABS containers (UL94-HB standard, UL94-V0 optional), the DG series batteries are valve-regulated, maintenance-free, and safe for use in various industrial and renewable energy applications.
Quick Detail
| Product Series: | PITTAR DG (Deep Cycle GEL) Series |
| Electrolyte Technology: | Pure GEL (Patented Gel Electrolyte) |
| Core Advantage: | 2 times cyclic life compared to standard series |
| Design Life: | 15 to 20 years (floating charge, depending on model) |
| Applications: | Solar & wind energy systems, marine, deep discharge UPS, and other extreme environment applications |
| Temperature Range: | Wide operating temperature (Discharge: -40°C ~ 60°C) |
| Self-Discharge: | Low self-discharge rate (less than 2% per month at 20°C) |
Applications
· Solar & Wind Energy Systems
· Marine & Boat Applications
· Deep Discharge UPS (Uninterruptible Power Supply)
· Standby Power Systems
· Frequent Cyclic Discharge Applications in Extreme Environments
Specifications
| Parameter | Details |
| Voltage Options | 2V, 6V, 12V |
| Capacity Range | 26Ah ~ 3000Ah (various models) |
| Chemistry | Pure GEL (Valve Regulated Lead Acid – VRLA) |
| Design Life | 15 – 20 years (floating charge) |
| Cycle Life | 2 times the standard series |
| Operating Temp. (Discharge) | -40°C ~ 60°C |
| Operating Temp. (Charge) | -20°C ~ 50°C |
| Storage Temp. | -40°C ~ 60°C |
| Self-Discharge | < 2% per month at 20°C |
| Container Material | A.B.S. (UL94-HB / UL94-V0 Optional) |
| Certifications | ISO 9001, ISO 14001, OHSAS 18001, CE |
Competitive Advantage
1. Pure GEL Technology: Patented gel electrolyte ensures superior deep discharge recovery and longer cycle life.
2. Higher Cycle Life: Offers 2 times the cyclic life compared to standard series batteries.
3. Long Design Life: 15 to 20 years of floating design life for long-term reliability.
4. Excellent Temperature Tolerance: Stable performance from -40°C to 60°C.
5. Low Maintenance: Valve-regulated, sealed design with low self-discharge rate.
6. Multiple Certifications: ISO 9001, ISO 14001, OHSAS 18001, and CE approved.
