LiFePO4 Lithium Battery Pack for Electric Vehicles 48V / 64V 15Ah – 50Ah Long Life & High Power
LiFePO4 Lithium Battery Pack for Electric Vehicles 48V / 64V 15Ah – 50Ah Long Life & High Power
- Overview
- Quick Details
- Specifications
- Description
- Applications:
- Tag:
- Recommended Products
Overview
Quick Details
| Place of Origin | China |
|---|---|
| Brand Name | PittarPower |
| Model Number | LI-MOTOR-4815 / LI-MOTOR-6020 / LI-MOTOR-6030 / LI-MOTOR-6050 |
| Certification | CE, RoHS (Assumed based on standard export requirements) |
Specifications
| Parameter | LI-MOTOR-4815 | LI-MOTOR-6020 | LI-MOTOR-6030 | LI-MOTOR-6050 |
|---|---|---|---|---|
| Rated Voltage | 51.2V | 64V | 64V | 64V |
| Rated Capacity | 15Ah | 20Ah | 30Ah | 50Ah |
| Rated Power | 720Wh | 1280Wh | 1920Wh | 3200Wh |
| Compatible Motor | ≤400W | ≤1200W | ≤1800W | ≤2000W |
| Protection Grade | IP65 | IP65 | IP65 | IP65 |
| Max Continuous Charge | 5A | 10A | 15A | 20A |
| Max Continuous Discharge | 15A | 40A | 50A | 80A |
| Dimension (mm) | 250x140x70 | 328x180x155 | 300x180x170 | 400x235x169 |
| Weight (kg) | 5.8 | 9.5 | 14.2 | 23.35 |
| Battery Type | LiFePO₄ | LiFePO₄ | LiFePO₄ | LiFePO₄ |
| Communication | Bluetooth (std) / 1-Wire / RS485 / CAN (opt.) |
Description
Power Your Ride with Li-Motor’s Premium Lithium Battery Solutions
Li-Motor is a dedicated brand providing safe, reliable, and practical electric lithium battery solutions for 2/3/4-wheel electric vehicles. Our Electric Two-Wheeler Series (models 4815, 6020, 6030, 6050) is designed for a wide range of e-bikes, e-mopeds, and e-motorcycles, offering exceptional performance and durability.
Key Features & Competitive Advantages:
- Ultra-Safe LiFePO₄ Chemistry: Unlike standard lithium-ion batteries, LiFePO₄ offers superior thermal and chemical stability, eliminating the risk of explosion or combustion for maximum safety.
- Long Cycle Life: Engineered for up to 10+ years of service life with high charge-discharge cycles, significantly reducing the total cost of ownership.
- Smart BMS Protection: Each pack features an intelligent Jiabaida BMS that monitors voltage, current, and temperature, preventing overcharge, over-discharge, overcurrent, and short circuits.
- IP65 Protection Grade: Fully protected against dust ingress and low-pressure water jets, making it suitable for outdoor use in various weather conditions.
- Fast Charging Capability: Supports 3-hour fast charging, minimizing downtime and getting you back on the road quickly.
- Smart App Control: Standard Bluetooth connectivity allows you to monitor battery status (voltage, capacity, temperature) directly from your smartphone.
- Flexible Communication: Supports 1-Wire / RS485 / CAN bus (optional) for seamless integration with the vehicle’s main controller.
Applications:
- Electric Bicycles (E-bikes)
- Electric Mopeds & Scooters
- Light Electric Motorcycles
- Short-distance Daily Commuting
- Food Delivery and Courier Services
- Small Cargo and Utility Vehicles
