PITTAR DC Series Deep Cycle VRLA Battery 2V/6V/12V 26Ah-3000Ah for Solar Energy Storage, UPS, Telecom & Medical Equipment
- Overview
- Quick Detail
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
The PITTAR DC Series batteries deliver superior high integrity and reliability. Unlike standard standby batteries, they are specially designed to withstand repeated deep-discharge cycles. By utilizing strong grids, thick plates, and a special active material formula, the DC series offers a remarkable 30% more cyclic life than the standby series, ensuring long-term value and reduced replacement costs. The advanced AGM (Absorbent Glass Mat) technology makes them maintenance-free, leak-proof, and safe for transportation. With a wide operating temperature range and a low self-discharge rate, these batteries are ready to perform under the most challenging conditions.
Quick Detail
The PITTAR DC (Deep Cycle) Series is a premium range of Valve Regulated Lead Acid (VRLA) batteries specifically engineered for frequent cyclic charging and discharging. Available in 2V, 6V, and 12V configurations with capacities ranging from 26Ah to 3000Ah, these batteries are the ideal power solution for demanding renewable energy and backup power applications. They are also known as solar batteries, deep discharge batteries, or cyclic use batteries.
Applications
· Solar & Wind Renewable Energy Storage: Ideal for off-grid and hybrid power systems.
· Telecom & Broadband: Reliable backup power for base stations and data centers.
· UPS Systems: Backup power for critical infrastructure.
· Mobility & Medical Equipment: Power for electric wheelchairs, scooters, and hospital devices.
· Cable TV & Security Systems: Stable power for alarms and CCTV.
Specifications
| Parameter | Specification (Typical for DC series) |
| Battery Type | Valve Regulated Lead Acid (VRLA), AGM |
| Design Life | 8 - 12 years (12V models) / 20 years (2V models) @ 25°C Float Charge |
| Capacity Range | 26Ah to 3000Ah @ 10hr or 20hr rate |
| Voltage Range | 2V, 6V, 12V per unit |
| Self Discharge | < 3% per month @ 25°C |
| Storage Time | Up to 6 months @ 25°C (recharging required after) |
| Max. Charging Current | Varies by model (e.g., 0.3C) |
| Float Charging Voltage | 2.27~2.30 VPC/6.80~6.90V (6V)/13.6~13.8V (12V) @ 25°C |
| Cycle Use Voltage | 2.43~2.47 VPC/7.30~7.40V (6V)/14.6~14.8V (12V) @ 25°C |
| Temp. Compensation | -3mV/°C/Cell (Float) / -4mV/°C/Cell (Cycle) |
| Operating Temp. | Discharge: -20°C~60°C / Charge: 0°C~50°C / Storage: -20°C~60°C |
| Container Material | A.B.S. (UL94-HB, UL94-V0 Optional) |
Competitive Advantage
· 30% Longer Cycle Life than standard standby batteries.
· Excellent Deep Discharge Recovery due to specialized thick plate design.
· Low Self Discharge Rate (less than 3% per month) for long storage.
· Wide Operating Temperature range for use in harsh environments.
· Full Certifications: ISO, CE, UL94-V0 (optional) ensuring high safety and quality.
· Maintenance-Free: VRLA technology eliminates the need for water topping.
