Wall-Mounted LiFePO4 Lithium Battery 25.6V / 51.2V 100Ah - 600Ah Long Cycle Life Solar Energy Storage System Home Backup Power
- Overview
- Quick Detail
- Features
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
Our Wall-Mounted LiFePO4 Battery is a high-performance, drop-in replacement for traditional lead-acid batteries, designed for modern energy storage systems. Utilizing advanced Lithium Iron Phosphate chemistry, this battery offers superior safety, longer lifespan, and higher efficiency.
The wall-mounted design saves valuable floor space and allows for easy installation in homes, offices, and commercial settings. With a modular design, you can connect up to 16 units in parallel to scale your energy capacity as needed.
Quick Detail
| Type: | Wall-Mounted Lithium Iron Phosphate (LiFePO4) Battery |
| Nominal Voltage: | 25.6V / 51.2V |
| Nominal Capacity: | 100Ah ~ 600Ah |
| Energy: | 2.56kWh ~ 30kWh |
| Cycle Life: | >4000 ~ >8000 cycles (at 0.2C, 100% DOD) |
| Application: | Solar/Wind Energy Storage, UPS, Backup Power, Telecom, Medical Equipment |
| Design: | Modular, wall-mounted, space-saving metal case |
Features
· Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than lead-acid batteries, reducing replacement costs.
· Lighter Weight: About 40% of the weight of a comparable lead-acid battery, making installation easier.
· Higher Power: Delivers twice the power of a lead-acid battery, even at high discharge rates.
· Wider Temperature Range: Operates reliably from -20℃ to 60℃.
· Superior Safety: The LiFePO4 chemistry eliminates the risk of explosion or combustion due to overcharging, short circuits, or high impact.
· High Efficiency: Charge efficiency up to 100% and discharge efficiency of 96~99%.
Applications
· Solar / Wind Energy Storage Systems
· UPS (Uninterruptible Power Supply) and Backup Power
· Electric Vehicles and Electric Mobility
· Telecommunication Base Stations
· Medical Equipment
· Lighting Systems
Specifications
| Parameter | Value |
| Nominal Voltage | 25.6V / 51.2V |
| Nominal Capacity | 100Ah ~ 600Ah (C5, 25℃) |
| Energy | 2.56kWh ~ 30kWh |
| Internal Resistance | ≤20mΩ |
| Cycle Life | >4000 ~ >8000 cycles @0.2C 100% DOD |
| Self-Discharge | <3% per month |
| Charge Efficiency | 100% @0.2C |
| Discharge Efficiency | 96~99% @1C |
| Charge Temperature | 0℃ to 45℃ |
| Discharge Temperature | -20℃ to 60℃ |
| Enclosure | Metal Case (Wall-Mounted) |
| Communication (Optional) | RS485 / CAN |
Competitive Advantage
· Drop-in Replacement: Directly replaces lead-acid batteries without system modifications.
· Space-Saving Design: Wall-mounted structure optimizes space utilization.
· Scalability: Supports parallel connection of up to 16 units for larger energy needs.
· Eco-Friendly: No heavy metals, fully recyclable materials.
· Low Maintenance: No need for watering or equalization charging.
