55D23LMF 12V 60Ah Sealed Maintenance Free Car Battery – JIS D23 Group, High Cranking Power
Reliable Starting Battery for Passenger Cars – Maintenance-Free, Long Service Life, Strong Performance
- Overview
- Description
- Specifications
- Competitive Advantage
- Tags
- Recommended Products
Overview
- Brand Name: PITTAR
- Model Number: 55D23LMF
- JIS Group No.: D23
- Type: Sealed Maintenance Free (SMF) Automotive Battery
- Voltage: 12V
- Capacity (20HR): 60Ah
- Reserve Capacity (RC): 99 mins
- Standard: JIS (Japanese Industrial Standard)
- Terminal Layout: 0 (Left Positive)
- Terminal Type: B
- Dimensions (L×W×H×TH): 230 × 173 × 200 × 220 mm
- Weight (±3%): 16.5 kg
- Certification: ISO9001, ISO14001, UL, CE, GB/T 5008-2023
- Application: Passenger cars, light commercial vehicles, SUVs, and vans
Quick Detail
Description
The PITTAR 55D23LMF is a high-quality 12V sealed maintenance free automotive battery designed for reliable starting, lighting, and ignition (SLI) systems. It features expanded lead-calcium alloy grids and advanced glass fiber separators, ensuring excellent high-current discharge characteristics, low self-discharge, strong cranking performance, and long shelf life. The completely sealed design eliminates the need for water addition, making it safe, clean, and maintenance-free. With a heat-sealed polypropylene container and anti-vibration construction, this battery prevents leakage and withstands various road conditions. The magic-eye indicator allows easy checking of charging status. Ideal for JIS D23 group applications with a constant charging voltage system of 13.5V–13.8V.
Specifications
| Parameter | Value |
|---|---|
| Model | 55D23LMF |
| JIS Group No. | D23 |
| Standard | JIS (Japanese Industrial Standard) |
| Voltage | 12V |
| Capacity (20HR) | 60Ah |
| Reserve Capacity | 99 mins |
| Length | 230 mm |
| Width | 173 mm |
| Height | 200 mm |
| Total Height | 220 mm |
| Weight (±3%) | 16.5 kg |
| Layout | 0 (Left Positive) |
| Terminal | B |
| Cover Material | PP |
| Pallet Qty | 147 pcs |
| Operating Temperature | -40°C to +60°C |
| Optimum Temperature | +10°C to +30°C |
Competitive Advantage
- 25 Years of Experience: 4 production bases, 13 million KVAH annual capacity.
- Global Standards: Meets JIS, EN, BCI, AS, and SA standards.
- Advanced Manufacturing: Imported automatic lines from Canada, Italy, Korea, and Germany.
- Certified Quality: ISO9001, ISO14001, UL, CE, ROHS approved.
- Overseas Sales: Over 60% of products exported worldwide.
