PITTAR HR Series High Rate VRLA Battery – 30% More Power for UPS & Data Center Backup (12V, 6V Options, 8-15 Years Design Life)
- Overview
- Quick Detail
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
The PITTAR HR (High Rate) series is a premium Valve Regulated Lead Acid (VRLA) battery specifically engineered for heavy load discharge applications. It delivers 30% more power output than standard series batteries, making it the ideal choice for high-rate, short-duration backup applications.
By utilizing strong grids, thick plates, and specially designed active material, the HR series offers a lower internal resistance (I.R.) and a lower self-discharge rate. This design ensures high power density, excellent high-rate discharge performance, and a long service life (8 to 15 years in float service depending on the model). It provides a reliable and maintenance-free power solution for critical systems.
Quick Detail
| Product Name: | High Rate Valve Regulated Lead Acid (VRLA) Battery |
| Main Application: | UPS systems, Data Centers, EPS, Emergency Lighting, High Power Standby |
| Core Specs: | 12V & 6V options; Power ranging from 16W to 850W (15-min rate); 8 to 15 years design life. |
Applications
· Data Centers & Server Rooms
· Uninterruptible Power Supplies (UPS)
· Emergency Power Systems (EPS)
· High Power Standby & Switching Equipment
· Telecommunication Systems
Specifications
| Feature | Standard Value |
| Battery Type | Valve Regulated Lead Acid (VRLA) |
| Voltage Options | 12V & 6V (Various models) |
| Design Life (Float) | 8 Years / 15 Years (Model Dependent) |
| Power Output | Offers 30% more power than standard series |
| Internal Resistance | Low I.R. design for high-rate discharge |
| Self-Discharge | Very low self-discharge rate (< 3% per month at 25°C) |
| Operating Temp. (Discharge) | -20°C ~ 60°C |
| Operating Temp. (Charge) | 0°C ~ 50°C |
| Housing Material | ABS (UL94-V0 optional) |
| Certifications | ISO 9001, ISO 14001, OHSAS 18001, CE |
Competitive Advantage
· 30% Higher Power Density: Delivers significantly more power than standard VRLA batteries in the same footprint.
· Robust Design: Features strong grids and thick plates for enhanced durability and longer service life.
· Lower Internal Resistance: Ensures excellent high-rate discharge performance, perfect for UPS/EPS applications.
· World-Class Certifications: Fully certified under ISO 9001, ISO 14001, and OHSAS 18001 quality management systems.
· Wide Model Range: Available from 16W to 850W in both 6V and 12V configurations to suit various power needs.
