PITTAR RT Series 6V/12V General Purpose Valve Regulated Lead Acid (VRLA) Battery AGM Technology, 6~8Years Design Life, for UPS, Medical Equipment, Emergency Lighting & Security Systems
- Overview
- Quick Detail
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
| Place of Origin: | CHINA |
| Brand Name: | PITTAR |
| Model Number: | RT |
The PITTAR RT Series is a range of high-quality, general-purpose valve regulated lead acid (VRLA) batteries manufactured using advanced AGM (Absorbent Glass Mat) technology and high-purity raw materials. Designed for reliable standby power, the RT series offers a design life of 6 to 8 years in float charging service.
These batteries are maintenance-free, sealed, and leak-proof, ensuring safe operation in a wide variety of environments. They meet multiple international and national standards including IEC, JIS, BS, GB/T, and YD/T, and are certified with CE, ISO 9001, ISO 14001, and OHSAS 18001.
With a low self-discharge rate of less than 3% per month at 25°C, RT series batteries can be stored for up to 6 months without recharging. They deliver consistent performance and high reliability, making them an ideal choice for critical backup power applications.
Quick Detail
Also Known As: VRLA battery, AGM battery, sealed lead acid battery, maintenance-free battery, standby power battery
Main Applications: UPS/EPS, medical equipment, emergency lighting, security systems, alarm systems, telecommunications, electronic instruments
| Core Specifications | |
| Voltage options: | 6V or 12V |
| Capacity range: | from 1.3Ah up to 28Ah (20-hour rate) |
| Design life: | 6~8 years in float service |
| Low self-discharge: | <3% per month at 25°C |
Applications
· Uninterruptible Power Supplies (UPS/EPS)
· Medical equipment
· Emergency lighting systems
· Security and alarm systems
· Telecommunications equipment
· Electronic instruments and control systems
Specifications
| Parameter | Value |
| Voltage Per Unit | 6V or 12V |
| Nominal Capacity | 1.3Ah ~ 28Ah @ 20-hour rate (to 1.75V/cell @ 25°C) |
| Design Life | 6~8 years (float charging) |
| Technology | AGM (Valve Regulated) |
| Self Discharge | < 3% per month at 25°C; can be stored up to 6 months |
| Operating Temperature | Discharge: -20°C ~ 60°C / Charge: 0°C ~ 50°C / Storage: -20°C ~ 60°C |
| Standby Use Voltage | 13.7~13.9V (12V models) / 6.85~6.94V (6V models) @ 25°C |
| Cycle Use Voltage | 14.6~14.8V (12V models) / 7.30~7.40V (6V models) @ 25°C |
| Terminal Options | F1, F2, F3, F13-BP, T1, T2, T24 (depending on model) |
| Container Material | ABS (UL94-HB standard; UL94-V0 optional) |
Competitive Advantage
1. Long Service Life: 6~8 years design life in float service, thanks to advanced AGM technology and high-purity materials.
2. High Reliability: Excellent consistency and stable performance for critical standby applications.
3. Maintenance-Free: Sealed construction eliminates the need for water addition and prevents acid leakage.
4. Wide Operating Temperature: Suitable for harsh environments from -20°C to 60°C.
5. Low Self-Discharge: Allows long-term storage without frequent recharging.
6. International Certifications: CE, ISO 9001, ISO 14001, OHSAS 18001 – ensures global quality standards.
